Restyle System Dash Kit: The Alpine X009-GM navigation receiver includes Alpine's G-KTX-009-GM Restyle System dash kit which allows the aftermarket head unit to fit seamlessly into select Chevrolet and GMC trucks and SUVS. The dash kit is made of specially formed OEM-grade, high-quality, high-strength ABS plastic that has been color-matched to the factory dash.. View and Download Alpine X009 quick reference manual online. 9-INCH ADVANCED NAVI STATION. X009 car navigation system pdf manual download. Also for: X008u, Ine-w957hd.
The Alpine X009-GM includes built-in GPS navigation with detailed maps and turn-by-turn directions to help drivers reach their destinations efficiently. It also offers Bluetooth connectivity for hands-free calling and streaming music from compatible devices.. the X009. This is where Sync module and the SW2 wire are located. Can bus wires can also be found at the Sync module. (see step 5 for color code) 5 Access the ODBII connector located under the driver side dashboard. Connect the YELLOW/BROWN wire from the Alpine harness to the WHITE wire located at pin 14 of the OBDII connector. Connect the RED/
